2250 2520 914 Material Wide Wire Mesh

Place of Origin ANPING,CHINA
Brand Name JIUFU
Certification ISO
Model Number JF-6002
Minimum Order Quantity 30 Square Meter
Price negotiation
Packaging Details Wooden Box
Delivery Time 7-20 days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 10000 Square Meter per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Wide Wire Mesh Material 2250 2520 914
Hole Type Square Hole Wire Diameter 0.12-0.8mm
Mesh Count 90x60 Mesh Width 1.5-6.5m
Application Industry, Mining, Petroleum, Chemical, Food Usage Filter
Feature Acid Resistance Color Natural
High Light

2250 Wide Wire Mesh

,

2520 Wide Wire Mesh

,

2250 wide mesh screen

Leave a Message
Product Description

2250 2520 914 Material Wide Wire Mesh





Stainless steel wide wire mesh, also known as stainless steel screen, stainless steel woven mesh, stainless steel filter mesh, stainless steel wire mesh, etc.



Stainless steel wide wire mesh can be divided into: extra wide stainless steel wire mesh, heavy duty stainless steel wire mesh.



Production process: the warp and weft wire diameters are the same, each diameter wire crosses up and down every two (or more) weft wires, and each weft wire crosses every two (or more) diameter wires. It is made by threading a fork up and down.



Stainless steel wide wire mesh weaving method: plain weave, twill weave



Stainless steel wide wire mesh material: 201, 304, 304L, 321, 316, 316L, 310S, 2250, 2520, 914 and other materials



Stainless steel wide wire mesh width: common widths are 1 meter, 1.2 meters, 1.5 meters, more than 2 meters to 6 meters can be customized



Stainless steel wide wire mesh length: 30 meters, according to customer requirements.



Wide Wire Mesh Specification:



Mesh Count Wire Diameter Opening Size

Material
8
0.80mm
2.375mm
304,304L,316,316L
10
0.60mm
1.94mm
304,304L,316,316L
12
0.50mm
1.61mm
304,304L,316,316L
14
0.50mm
1.314mm
304,304L,316,316L
30×40
0.30mm×0.30mm
0.54mm×0.33mm
304,304L,316,316L
36×40
0.27mm×0.27mm
0.43mm×0.36mm
304,304L,316,316L
40
0.23mm
0.405mm
304,304L,316,316L
40
0.25mm
0.385mm
304,304L,316,316L
50
0.21mm
0.298mm
304,304L,316,316L
50
0.23mm
0.278mm
304,304L,316,316L
40×60
0.25mm×0.28mm
0.635mm×0.143mm
304,304L,316,316L
50×70
0.22mm×0.24mm
0.288mm×0.122mm
304,304L,316,316L
60×80
0.19mm×0.21mm
0.233mm×0.0.107mm
304,304L,316,316L
60×90
0.15mm×0.20mm
0.273mm×0.082mm
304,304L,316,316L
60×100
0.12mm×0.15mm
0.303mm×0.104mm
304,304L,316,316L



2250 2520 914 Material Wide Wire Mesh 0



2250 2520 914 Material Wide Wire Mesh 1



2250 2520 914 Material Wide Wire Mesh 2
